Description
Camera
- Image Sensor: 3K CMOS
- Maximum Resolution: 2960 × 1665
- Minimum Illumination: 0.01 Lux @ F1.6, AGC ON; 0 Lux with IR
- Shutter Speed: PAL: 1/12.5 s to 1/50,000 s; NTSC: 1/15 s to 1/50,000 s
- Day & Night: ICR
- Signal System: PAL/NTSC
- Adjustment: Pan 0°–360°, Tilt 0°–90°, Rotate 0°–360°
Lens
- Lens Type: 2.8 mm / 3.6 mm Fixed Lens
- Lens Mount: M12
- Field of View:
- 2.8 mm: H 105°, V 62°, D 131°
- 3.6 mm: H 80°, V 48°, D 112°
Audio
- Built-in Microphone: Pickup range up to 5 m
- Built-in Speaker: 2 W, range up to 5 m
- Audio Features: Echo Cancellation, AI Noise Reduction, Automatic Gain Control
- Two-Way Audio: Supported
Illumination
- Supplement Light: Smart IR / White Light
- IR Range: Up to 30 m
- White Light Range: Up to 20 m
Image Features
- Frame Rate: Up to 3K @ 25 fps
- Day/Night Mode: Auto / Color
- WDR: Digital WDR
- Noise Reduction: 2D DNR
- Image Enhancement: DWDR, BLC, HLC, Global, HLS
- White Balance: Auto / Manual
- Image Settings: Anti-Banding, Brightness, Sharpness, Smart IR
Interface
- Video Output: 1 × HD Analog Output
General
- Power Supply: 12 VDC ±25%, Max. 5.4 W
- Material: Metal
- Dimensions: 179 × 66 × 69.1 mm
- Weight: Approx. 410 g
- Operating Temperature: -40°C to 60°C
- Operating Humidity: Up to 90%, non-condensing
- Communication: HIKVISION-C
- Language: English
Protection & Approval
- Protection Rating: IP67 – Water and Dust Resistant
