PIXMA G3780

Description

Print Engine

• High-density print head with 1,792 nozzles.

• Uses GI-71 (standard) and GI-71S (high-yield) ink bottles.

  • Black: pigment-based; Cyan, Magenta, Yellow: dye-based.

• Maintenance cartridge: Model MC‑G07.

• Maximum print resolution: 4,800 × 1,200 dpi.

Print Performance

• ISO print speeds (A4 simplex): approximately 11 ipm (mono), 6 ipm (color).

• Duplexing speed: ~8.3 ipm (mono), 5.2 ipm (color).

• First-page output: ~9 sec (mono), 14 sec (color).

• Borderless 4″×6″ photo: ~45 sec.

• Print width: up to 8″ (203 mm); borderless up to 8.5″ (216 mm).

Scanning

• Flatbed scanner using CIS (Contact Image Sensor) technology.

• Optical resolution: 600 × 1,200 dpi.

• Supports scanning up to A4/Letter size.

Copy Functions

• Copy speed: ~23 sec / 3.2 ipm (color, simplex).

• Maximum copies in one batch: 99 pages.

• Enlargement/reduction range: 25%–400%.

• Copy features: borderless copy, two-sided copying, 2-on-1, 4-on-1, frame erase, ID copy.

Paper Handling

• Automatic duplex printing for plain paper.

• Rear input tray capacity:

  • Plain paper (A4/LTR): 100 sheets.

  • High-resolution/coated media: 80 sheets.

  • 4″×6″ glossy photo paper: 20 sheets.

Media Compatibility

• Supports plain, high-resolution, glossy, matte, luster, semi-gloss, double-sided matte papers, envelopes, and more.

• Compatible sizes: A4, A5, A6, B5, Letter, Legal, various envelopes (COM10, DL, C5, Monarch), popular photo sizes (4″×6″, 5″×7″, 7″×10″, 8″×10″), square prints, and custom sizes (width 55–216 mm; length 89–1,200 mm).

• Borderless printing supports all major photo and document sizes.

Network & Print Solutions

• Supports network protocols: SNMP, HTTP, TCP/IP (IPv4/IPv6).

• Wireless connectivity: IEEE 802.11 b/g/n (2.4 GHz) with support for 10-13 channels (depending on region).

• Security: WPA‑PSK (AES), WPA2‑PSK (AES), WPA3‑SAE (AES).

• Mobile and cloud printing support: Canon PRINT app, Easy‑PhotoPrint Editor, Creative Park, AirPrint, Mopria Print Service, Canon Print Service, and Direct Wireless printing.

User Interface & Controls

• Features a 1.35-inch monochrome LCD (square).

• Offers intuitive guided instructions for operations and setup.

Power & Operating Conditions

• Power supply: AC 100–240 V, 50/60 Hz.

• Power consumption:

  • Off: ~0.1 W

  • Standby (USB connected): ~0.8 W

  • In operation: ~18 W

• Acoustic noise: ~49 dB (mono A4 printing).

• Duty cycle: up to 3,000 pages/month; recommended monthly volume: 150–1,500 pages.

• Operating temperatures: 5–35 °C; humidity: 10–90% RH (operating) / 10–80% RH (recommended).

• Storage: 0–40 °C; 5–95% RH.

• Quiet Mode available.

Physical Specs

• Dimensions (WxDxH):

  • Closed: approx. 416 × 363 × 177 mm

  • With trays extended: approx. 416 × 555 × 268 mm

• Weight: approx. 6.5 kg

Ink Yield (Approximate & A4 Color Documents)

• GI‑71 Bottles:

  • Black: ~6,000 pages (Eco mode: ~7,600)

  • Color set (C/M/Y): ~7,700 pages (Eco mode: ~8,100)

• GI‑71S Bottles:

  • Black: ~3,100 pages (Eco mode: ~3,900)

  • Color set: ~4,400 pages (Eco mode: ~4,600)

• 4″×6″ Photos (PP-201 Borderless):

  • Color bottles: ~2,200 photos (GI‑71); ~1,200 photos (GI‑71S).
