Description
Print Technology
-
Print Method: PrecisionCore Micro TFP printhead
-
Ink Type: DURABrite Pro pigment ink
-
Nozzles: 5,784 per color (CMYK) + 5,784 black
-
Minimum Droplet Size: 3.8 picoliters
Print Performance
-
Print Speed: Up to 40 pages per minute (black & color, simplex and duplex)
-
First Page Out Time: Approx. 6.4 seconds (black and color)
-
Print Resolution: Up to 600 × 2,400 dpi
-
Monthly Duty Cycle: Max 384,000 pages
-
Recommended Monthly Volume: 2,800 – 30,000 pages
Copying
-
Copy Speed: Up to 40 ipm (images per minute)
-
Copy Resolution: 600 × 600 dpi
-
Maximum Copies: Up to 9,999
-
Zoom Range: 25% – 400%
-
Max Copy Size: A4
Scanning
-
Scanner Type: Color flatbed and ADF with single-pass duplex scanning
-
Optical Resolution: 600 × 600 dpi
-
Interpolated Resolution: Up to 9,600 dpi
-
Scan Speed:
-
50 ipm (single-sided)
-
100 ipm (double-sided)
-
-
File Formats: JPEG, TIFF, PDF, PNG, BMP
-
Scan Destinations: Email, FTP, Network Folder, USB, PC, SharePoint
Fax (Optional)
-
Fax Type: Mono and Color Fax
-
Modem Speed: 33.6 kbps
-
Memory: 6 MB
-
Features: Broadcast, fax to folder/email, up to 2,000 speed dials
Paper Handling
-
Standard Input Capacity: 600 sheets (500-sheet cassette + 100-sheet multipurpose tray)
-
Optional Input: Up to 2 additional 500-sheet cassettes (total 2,100 sheets)
-
ADF Capacity: 100 sheets
-
Output Capacity: 300 sheets
-
Supported Media Sizes: A4, A5, Legal, Letter, and others
-
Supported Media Weights:
-
Standard trays: 52–160 g/m²
-
Multipurpose tray: up to 300 g/m²
-
Connectivity
-
Interfaces: USB 3.0, Ethernet (10/100/1000), optional Wi-Fi and Wi-Fi Direct
-
Mobile Printing: AirPrint, Mopria, Epson Smart Panel
-
Protocols: IPP, LPD, WSD, SNMP, HTTP, DHCP, mDNS, etc.
Security Features
-
WEP, WPA2, WPA3
-
SSL/TLS encryption
-
PIN code release
-
IP filtering
-
Optional encrypted HDD (320 GB) with AES-256 encryption
-
Image overwrite, LDAP authentication
User Interface
-
Display: 10.1-inch color touchscreen (tiltable)
-
Languages: Multiple UI languages supported
Operating Environment
-
Temperature: 10°C – 35°C
-
Humidity: 15% – 85% RH (non-condensing)
Power Consumption
-
Operating: ~84 W
-
Ready Mode: ~36–39 W
-
Sleep Mode: ~0.9 W
-
Power Off: ~0.1 W
-
TEC (Typical Energy Consumption): 0.19 kWh/week
Physical Specifications
-
Dimensions (W × D × H): 465 × 490 × 570 mm (base unit)
-
Weight: Approx. 56.3 kg (58.7 kg with ink supplies)
-
Height with Extra Trays:
-
2-tray: ~670 mm
-
3-tray: ~938 mm
-
Software & Features
-
PCL5c/6, PostScript 3, ESC/P-R
-
Epson Document Capture Pro
-
Epson Open Platform support
-
Optional HDD for document storage and workflow
-
Integration with enterprise solutions and cloud services
