EB-X52 XGA 3LCD Projector

XGA Resolution
Displaying clear and crisp visuals thanks to its XGA resolution, the Epson EB-X52’s high resolution is able to support vivid display on large screen sizes

Easy Maintenance and Longer Lamp Life
A long lamp life reduces maintenance and costs. The lamp will last up to 12,000 hours in ECO mode. Cut down on the frequency of lamp replacements, saving you time and money, and lowering the total cost of ownership.

Various Interfaces
Epson business projectors support a wide range of connectivity options. Works with various HDMI capable equipments.

Flexible Display Size
Why settle for smaller screen when you can have more 120″ and even up to 300″? EB-X52 supports a variety of aspect ratio and display size up to 300″ diagonal.

USB-A Power Supply
Connect external streaming device such as Epson ELPAP12 Android TV Dongle to turn your projector to be a Smart display for you to access to various entertainment contents such as Youtube, Internet browser etc.

Split Screen Capability
Use the projector to show 2 different images from 2 different devices at the same time using the split screen function. Example, you can now show your presentation on one side while seeing the video on another side.

Category: Tags: , , , Brand:


Description

Display & Image

  • Projection System: RGB liquid crystal shutter (3LCD)
  • Native Resolution: XGA (1024 × 768)
  • Aspect Ratio: 4:3
  • Brightness:
    • 3,800 lumens (White & Color)
    • 2,500 lumens (Eco mode)
  • Contrast Ratio: 16,000:1
  • Color Processing: 3LCD for equal color/white brightness

Projection & Lens

  • Zoom: Optical zoom 1.0 – 1.2x
  • Focus: Manual
  • Throw Ratio: 1.48 – 1.77
  • Screen Size: 30″ – 300″
  • Projection Distance: approx. 0.89 m – 10.95 m
  • Keystone Correction:
    • Vertical: ±30°
    • Horizontal: ±30°

Lamp & Light Source

  • Lamp Type: 210W UHE lamp
  • Lamp Life:
    • Normal: up to 6,000 hours
    • Eco: up to 12,000 hours

Audio & Noise

  • Built-in Speaker: 2W mono
  • Fan Noise:
    • Normal: 37 dB
    • Eco: 28 dB

Connectivity

  • HDMI: 2 × HDMI (HDCP 1.4)
  • USB Ports:
    • USB-A (power / media / firmware)
    • USB-B (service / firmware)
  • Wireless: Optional (via ELPAP11 adapter)
  • Other Features:
    • USB power output (5V/2A)
    • Split-screen display

Features

  • 3LCD technology for brighter and more accurate colors
  • Auto vertical keystone + horizontal slider
  • Split screen (2 inputs at once)
  • Direct Power On/Off
  • Instant Off (no cooling wait)

Power & Performance

  • Power Supply: 100–240V AC ±10%, 50/60Hz
  • Power Consumption:
    • Normal: ~332W
    • Eco: ~231W

Physical Specifications

  • Dimensions (W × D × H): 302 × 234 × 77 mm
  • Weight: approx. 2.5 kg
  • Operating Temperature: 5°C – 40°C

Additional Details

  • LCD Panel Size: 0.55” (3 panels)
  • Pixel Count: 786,432 pixels
  • Air Filter Maintenance: up to 6,000–12,000 hours
  • Startup Time: < 7 seconds
