Description
Specifications:
Camera & Image
-
Image Sensor: 1/2.8″ Progressive Scan CMOS
-
Resolution: Up to 1920 × 1080 (2 MP)
-
Frame Rate: 25 fps @ 1080p (50 Hz) / 30 fps @ 1080p (60 Hz)
-
Minimum Illumination:
• Color: ~0.01 Lux (F1.2, AGC ON)
• 0 Lux with IR on -
Shutter Speed: 1/3 s to 1/100,000 s
-
Day/Night: IR cut filter for clear day & night imaging
-
WDR: 120 dB Wide Dynamic Range for improved contrast in bright/dark scenes
-
Image Enhancements: BLC, 3D DNR (noise reduction)
-
Adjustable Angles: Pan 0–360°, tilt 0–75°, rotate 0–360° for flexible mounting
Lens
-
Fixed Lens Options: 2.8 mm, 4 mm, or 6 mm focal lengths
-
Field of View (FOV):
• 2.8 mm: ~109° horizontal
• 4 mm: ~88° horizontal
• 6 mm: ~54° horizontal -
Lens Mount: M12
-
Aperture: F1.6 / F2.0 depending on spec detail source
Illumination & IR
-
Infrared Range: Up to 30 m night vision
-
IR Wavelength: 850 nm for effective low-light visibility
Video & Compression
-
Video Compression: H.265+, H.265, H.264+, H.264, MJPEG
-
Bitrate Range: 32 Kbps to ~8 Mbps
-
Day/Night Mode Settings: Auto, Day, Night, Schedule
-
Region of Interest (ROI): Support fixed ROI on main stream
Network Functions
-
Protocols: TCP/IP, HTTP/S, FTP, DHCP, DNS, RTSP, SMTP, SNMP, IGMP, UPnP, 802.1X, QoS, IPv6, etc.
-
Live View: Supports up to 6 simultaneous channels
-
Clients: Compatible with Hik-Connect, iVMS-4200, Hik-Central
-
ONVIF/ISAPI: Supported for integration with NVRs and third-party systems
-
User Levels: Up to 32 users (admin/operator/user)
General
-
Power: 12 VDC & PoE (802.3af, Class 3)
-
Power Consumption: Max ~6.5 W
-
Ingress Protection: IP67 weather-proof rating (dust/water resistant)
-
Operating Temp: –30 °C to 60 °C
-
Dimensions: ~Ø114.6 × 82.1 mm
-
Weight: ~400 g (camera)
Smart Features
-
Smart Detection: Line crossing & intrusion detection with alerts
-
Image Settings: Adjustable saturation, brightness, contrast, sharpness via app/software
-
Privacy & Security: Password protection, IP filter, privacy mask options
