Description
Print Engine & Ink System
-
Print Head: FINE print head with 18,432 nozzles (1,536 per color), user-replaceable.
-
Ink Type: LUCIA PRO II pigment-based inks in 12 cartridges:
-
Matte Black
-
Photo Black
-
Gray
-
Photo Gray
-
Cyan
-
Photo Cyan
-
Magenta
-
Photo Magenta
-
Yellow
-
Red
-
Blue
-
Chroma Optimizer
-
-
Ink Capacity: Standard 80 ml per cartridge.
-
Maintenance Cartridge: MC‑20, user-replaceable.
-
Ink Level Detection: By dot count and electrode.
Print Resolution & Droplet Size
-
Maximum Resolution: 2,400 dpi horizontally × 1,200 dpi vertically.
-
Minimum Droplet Size: 4 picoliters.
Print Speeds (Approximate)
-
A2 Size using Photo Paper Pro Platinum (PT‑101, high quality):
-
Monochrome: ~8 min 40 sec
-
Color: ~6 min
-
-
A2 using Photo Paper Pro Luster (LU‑101):
-
Standard: ~3 min 40 sec
-
High: ~6 min
-
-
A2 using Premium Matte (PM‑101):
-
High: ~5 min 35 sec
-
Highest: ~7 min 30 sec
-
-
A3+ Size (PP‑201 or LU‑101):
-
Standard: ~2 min 25 sec
-
Media Handling & Support
-
Paper Feeding Paths:
-
Top feed tray
-
Manual single-sheet feed
-
Multi-purpose tray (e.g., for printable discs)
-
-
Borderless Printing: Supported on virtually all edges (0 mm).
-
Margin Specifications (for bordered prints):
-
Top: 3 mm
-
Bottom: 5 mm
-
Left/Right: ~3.4 mm (or 6.4/6.3 mm for Letter/Legal)
-
-
Media Types Supported:
-
Plain, glossy, semi-gloss, Pro Luster, Pro Platinum, matte, fine art (smooth/rough), heavyweight and extra-heavyweight papers, canvas, Washi, long-form media, crystals, and more.
-
-
Supported Sizes:
-
Wide selection from small formats to A2, plus panorama up to 3,276.7 mm.
-
-
Media Thickness:
-
Top Tray: 0.1–0.3 mm (plain to 300 gsm).
-
Manual Feed Slot: up to 0.7 mm (specialty media up to 400 gsm).
-
-
Printable Dimensions:
-
Width: 89–432 mm (Top Tray), 203.2–432 mm (Manual)
-
Minimum length: 127 mm (Top Tray), 254 mm (Manual)
-
Maximum length: up to 3,276.7 mm
-
Connectivity & Software
-
Interfaces:
-
USB 2.0 (Hi-Speed)
-
Ethernet (auto-switching 10/100/1000 Mbps)
-
Wireless LAN (IEEE 802.11 b/g/n, 2.4 GHz)
-
-
Security Options:
-
Wired: IEEE 802.1X (EAP-TLS/TTLS/PEAP)
-
Wireless: WPA-PSK, WPA2-PSK, WPA3-SAE, and EAP-based variants
-
-
Printing Solutions:
-
Mobile/Cloud: AirPrint, Mopria Print Service, Canon PRINT app, Canon Print Service (Android), Direct Wireless, Cloud integration
-
Desktop Software: Professional Print & Layout, Media Configuration Tool, PosterArtist Lite, Easy‑PhotoPrint Editor
-
User Interface & Intelligent Features
-
3.0″ color LCD screen for navigating settings and monitoring ink levels.
-
Featured enhancements:
-
Automatic paper skew correction
-
Air-assisted feeding for accurate print placement
-
Non-firing detection and compensation to prevent drops/blind spots
-
Quiet Mode for reduced noise in operation
-
Chroma Optimizer for uniform gloss
-
Automatic/manual print-head alignment and wide/specific media support.
-
Performance & Acoustics
-
Power Requirements: AC 100–240 V, 50/60 Hz
-
Power Consumption:
-
Operating: ~38 W
-
Standby: ~1.2 W
-
Off: ~0.1 W
-
-
Noise Level: ~43 dB during 4″ × 6″ borderless print operations (Quiet Mode further reduces noise).
Operating Environment
-
Operating Temperature/Humidity: 5–35 °C; 10–90 % RH (non-condensing)
– Recommended: 15–30 °C; 10–80 % RH -
Storage Conditions: 0–40 °C; 5–95 % RH (non-condensing)
Physical Dimensions & Weight
-
Dimensions (W × D × H):
-
With trays retracted: ~723 × 435 × 285 mm
-
-
Weight: ~32.4 kg
Memory & Internal Specs
-
Standard Memory: 1 GB RAM
-
Printing Language: SG Raster (IVEC job control)
Page Yields (Approximate, A2 Using LU‑101 Paper)
-
On A2 monochrome:
-
Matte Black: ~1,455 pages
-
Photo Black: ~194 pages
-
Gray: ~102
-
Photo Gray: ~257
-
Photo Cyan: ~1,285
-
Cyan: ~830
-
Photo Magenta: ~1,065
-
Magenta: ~1,580
-
Yellow: ~1,305
-
Red: ~2,185
-
Blue: ~915
-
Chroma Optimizer: ~525
-
-
On A2 color output, yields vary per color (e.g., Matte Black ~1,830; Photo Black ~224; etc.).
