Description
Key Specifications
-
Display Technology: 3LCD (RGB shutter)
-
Native Resolution: WUXGA (1920 × 1200), Aspect Ratio 16:10
-
Brightness (White & Colour, Normal): ~ 3,700 ANSI lumens
-
Brightness (Eco Mode): ~ 2,400 ANSI lumens
-
Contrast Ratio (typical): ~ 16,000 : 1
Optics & Projection
-
Lens / Zoom: Manual zoom (1.0–1.2×), manual focus
-
F‑number (Aperture): ~ f/1.50 – f/1.71
-
Focal Length: ~ 20.42 mm (wide) to ~ 24.50 mm (tele)
-
Throw Ratio: ~ 1.38 – 1.68 :1 (wide to tele)
-
Keystone Correction: Vertical ±30° (auto); Horizontal ±30° (manual)
-
Screen size: ~ 30″ – 300″ diagonal
-
Projection Distance for those sizes: wide ~ 0.9‑10.98 m; tele ~ 0.87‑9.02 m
Lamp & Life
-
Lamp Type: UHE lamp, ~ 200 W
-
Lamp Life: ~ 10,000 hours in Normal mode; ~ 17,000 hours in Eco mode
Connectivity & Features
-
Inputs:
• 2× HDMI • 2× VGA (D‑Sub 15) -
Outputs & Others:
• VGA output, Audio in (mini‑jack) ×2, Audio out mini‑jack ×1
• USB Type A & B (for USB display, firmware, etc.), RS‑232C control, Built‑in wireless LAN -
Built‑in Speaker: ~ 5 W (mono)
Physical / Power / Environment
-
Weight: ~ 3.1 kg
-
Dimensions (W × H × D, excluding feet): ~ 364 × 87 × 248 mm
-
Noise Level: ~ 37 dB (Normal), ~ 28 dB (Eco)
-
Power Consumption: ~ 285 W (Normal); ~ 218 W (Eco); Standby ~0.3‑2 W depending on mode
-
Operating Temperature: ~ 5‑40 °C
-
Operating Altitude: up to ~ 3,048 m
