Description
Specifications:
| Print Head / Consumables | |
| Number of Nozzles | Total 4,352 nozzles |
| Ink Bottles (Type/Colours) | GI-76 (Pigment Ink/Black, Cyan, Magenta, Yellow) |
| Maintenance Cartridge | MC-G01 |
| Maximum Print Resolution | 600 (Horizontal) x 1,200 (Vertical) dpi |
| Print Speed*1 (Approx.) Click here for summary report Click here for Document Print and Copy Speed Measurement Conditions |
|
| Document (ESAT/Simplex)*2 | 24 / 15.5 ipm (Mono/Colour) |
| Document (ESAT/Duplex) | 13 / 10 ipm (Mono/Colour) |
| Document (FPOT Ready/Simplex)*3 | 5.5 / 7 sec (Mono/Colour) |
| Print Width | Up to 206.0 mm (8″) |
Paper Handling
| Print Margin | |
| Bordered Printing | Envelope (COM10, DL, C5, Monarch): Top/Bottom: 12.7 mm, Left/Right: 5.6 mm4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″: Top: 3 mm, Bottom: 5 mm, Left/Right: 3.4 mmSquare (127 x 127 mm): Top/Bottom/Left/Right: 6 mmOthers: Top/Bottom/Left/Right: 5 mm |
| Bordered Auto 2-Sided Printing | Top/Bottom/Left/Right: 5 mm |
| Supported Media | |
| Rear Tray | Plain Paper (64 – 105 g/m²) High Resolution Paper (HR-101N) Photo Paper Pro Luster (LU-101) Photo Paper Plus Glossy II (PP-201, PP-208) Matte Photo Paper (MP-101) Envelope |
| Cassette | Plain Paper (64 – 105 g/m²) |
| Paper Size | |
| Rear Tray | A4, A5, A6, B5, LTR, LGL, 4 x 6″, 5 x 7″, 7 x 10″, 8 x 10″, Square (127 x 127 mm), Envelope (COM10, DL, C5, Monarch), B-Oficio, M-Oficio, Foolscap, Legal (India), Executive
[Custom Size] |
| Cassette | A4, LTR, A5, B5, Executive
[Custom Size] |
| Auto 2-Sided Printing (Plain Paper: 64 g/m²) |
A4, LTR |
| Paper Weight | |
| Rear Tray | Plain Paper: 64 – 105 g/m² Canon Paper: Approx. 265 g/m² (Max.) (Photo Paper Plus Glossy II, PP-201) |
| Cassette | Plain Paper: 64 – 105 g/m² |
| Maximum Capacity | |
| Rear Tray | Plain Paper (A4/LTR, 64 g/m²): 100 Photo Paper Plus Glossy II (PP-201/PP-208, 4 x 6″): 20 Matte Photo Paper (MP-101, 4 x 6″): 20 |
| Cassette | Plain Paper (A4/LTR, 64 g/m²): 250 |
Network
| Protocol | SNMP, HTTP, TCP/IP (IPv4/IPv6) |
| TLS | 1.3 / 1.2 / 1.1 / 1.0 |
| Wired LAN | |
| Type | IEEE 802.3u (100BASE-TX) / IEEE 802.3 (10BASE-T) |
| Security | IEEE 802.1X (EAP-TLS/EAP-TTLS/PEAP) |
| Wireless LAN | |
| Type | IEEE 802.11b/g/n |
| Frequency Band | 2.4 GHz |
| Channel | 2.4 GHz: 1 – 13 (TW: Supported Channels: 1 – 11 only)*4 |
| Security | WPA-PSK (AES) WPA2-PSK (AES) WPA3-SAE (AES) WPA-EAP (AES)*5 WPA2-EAP (AES)*5 WPA3-EAP (AES)*5 |
| Direct Connection (Wireless LAN) | 2.4 GHz: Available |
Printing Solutions
| Canon Printing Apps | |
| Mobile (iOS/Android) | Canon PRINT, Easy-PhotoPrint Editor |
| PC (Windows/Mac) | Canon PRINT, Easy-PhotoPrint Editor, Easy-Layout Editor (Win only), PosterArtist Lite (Win only), PosterArtist Web (browser-based) |
| Mobile/Cloud Printing Solutions | AirPrint®, Mopria® Print Service, Canon Print Service (Android), Wireless Direct, Cloud Integration Service (via smartphone/tablet) |
System Requirements
| OS System Compatibility*6 | Windows 11 / 10 / 8.1 / 7 SP1, macOS 11.7.6 ~ 14 or later, ChromeOS |
General Specifications
| Operation Panel | |
| Display | 2-Line LCD |
| Interface | USB 2.0 |
| Operating Environment*7 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*8 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print)*9 | |
| Plain Paper | 49 dB(A) |
| Power Requirements | AC 100 – 240 V, 50/60 Hz |
| Power Consumption (Approx.) | |
| OFF | 0.05 W |
| Standby (USB connection to PC) | 0.8 W |
| Operation (USB connection to PC)*10 | 19 W |
| Duty Cycle | Up to 45,000 pages/month |
| Dimensions (W x D x H) (Approx.) | |
| Factory Configuration | 399 x 416 x 238 mm |
| Output/Trays Extended | 399 x 639 x 332 mm |
| Weight (Approx.) | 9 kg |
Page Yield*11
| Plain Paper Click here for more information |
A4 Colour Documents*12: GI-76 PGBK: 6,000 pages (Economy Mode*13: 9,000 pages) GI-76 C, M, Y: 14,000 pages (Economy Mode*13: 21,000 pages) |
